Overhead Crane for Metallurgy
This metallurgical overhead crane from Zhonggong is mainly designed for handling molten iron and steel in steel plants. It can transport the ladle containing molten steel to the refining furnace or ladle turret in continuous casting process. Currently, our overhead lifting systems have won great popularity among users due to state of the art technology, modern construction, high safety, economy and durability and easy maintenance. Contact Zhonggong anytime by phone or email to know more about the crane for metal processing before you buy it.
Technical Parameters of the Overhead Crane
| Capacity |
T |
5 |
| Span |
S (m) |
10.5 |
13.5 |
16.5 |
19.5 |
22.5 |
25.5 |
28.5 |
31.5 |
| Lifting height |
m |
16 |
| Lifting speed |
m/min |
12.5 |
| Trolley speed |
m/min |
39.5 |
| Crane speed |
m/min |
119.3 |
| Total weight |
kg |
14960 |
17140 |
18785 |
22060 |
24780 |
30830 |
34900 |
38720 |
| Max Wheel Load |
KN |
80 |
87 |
92 |
102 |
107 |
123 |
135 |
143 |
| Track |
|
P43 |
| Main dimension |
mm |
10.5 |
13.5 |
16.5 |
19.5 |
22.5 |
25.5 |
28.5 |
31.5 |
| Rail top to main top |
H |
1763 |
| Rail top to hook centre |
h |
71 |
| Wheelbase |
W |
3400 |
3550 |
5000 |
| Crane width |
B |
5150 |
5300 |
6020 |
| Hook left limitation |
L1 |
1600 |
| Hook right limitation |
L2 |
1250 |
| Trolley gauge |
K |
1400 |
| Capacity |
T |
10 |
| Lifting height |
m |
20 |
| Lifting speed |
m/min |
13 |
| Trolley speed |
m/min |
44.9 |
| Crane speed |
m/min |
114.9 |
| Total weight |
kg |
17480 |
19680 |
22200 |
25800 |
28570 |
33750 |
37910 |
41780 |
| Max Wheel Load |
KN |
112 |
120 |
130 |
138 |
145 |
160 |
171 |
180 |
| Track |
|
P43 |
| Main dimension |
mm |
10.5 |
13.5 |
16.5 |
19.5 |
22.5 |
25.5 |
28.5 |
31.5 |
| Rail top to main top |
H |
1876 |
1926 |
| Rail top to hook centre |
h |
602 |
552 |
| Wheelbase |
W |
4050 |
5000 |
| Crane width |
B |
5800 |
5940 |
6380 |
| Hook left limitation |
L1 |
1600 |
| Hook right limitation |
L2 |
1300 |
| Trolley gauge |
K |
2000 |
| Capacity |
T |
74./20 |
| Span |
S(m) |
13.5 |
16.5 |
19.5 |
22.5 |
25.5 |
28.5 |
31.5 |
| Lifting height |
m |
main hook 20 aux hook 22 |
| Lifting speed |
m/min |
main hoist6.4 aux hoist 9.7 |
| Trolley speed |
m/min |
37.2 |
| Crane speed |
m/min |
67.4 |
77 |
| Max Wheel Load |
KN |
188 |
196 |
209 |
218 |
231 |
242 |
253 |
| Track |
|
QU 100 |
| Main dimension |
mm |
13.5 |
16.5 |
19.5 |
22.5 |
25.5 |
28.5 |
31.5 |
| Rail top to main top |
H |
3521 |
3523 |
3525 |
3531 |
3533 |
| Rail top to hook centre |
h |
1866 |
1864 |
1862 |
1856 |
1856 |
| Crane width |
B |
8728 |
| Hook left limitation |
L1 |
2450 |
| Hook right limitation |
L2 |
2200 |
| Trolley gauge |
K |
4400 |
